| TRDE11-RC-090-032 |
2530140 |
90 | 32 | SDR11 | 8.2 | 85 | 203 | 3 |
CAD/Step
|
| TRDE11-RC-090-050 |
2530141 |
90 | 50 | SDR11 | 8.2 | 90 | 203 | 4.6 |
|
| TRDE11-RC-110-032 |
2530143 |
110 | 32 | SDR11 | 10 | 94 | 230 | 3 |
|
| TRDE11-RC-110-050 |
2530144 |
110 | 50 | SDR11 | 10 | 100 | 230 | 4.6 |
CAD/Step
|
| TRDE11-RC-125-063 |
2530145 |
125 | 63 | SDR11 | 11.4 | 112 | 265 | 5.8 |
CAD/Step
|
| TRDE11-RC-140-063 |
|
140 | 63 | SDR11 | 12.7 | 120 | 290 | 5.8 |
CAD/Step
|
| TRDE11-RC-140-075 |
2530147 |
140 | 75 | SDR11 | 12.7 | 130 | 300 | 6.8 |
CAD/Step
|
| TRDE11-RC-140-090 |
2530148 |
140 | 90 | SDR11 | 12.7 | 130 | 290 | 8.2 |
CAD/Step
|
| TRDE11-RC-140-110 |
2530149 |
140 | 110 | SDR11 | 12.7 | 141 | 300 | 10 |
CAD/Step
|
| TRDE11-RC-160-125 |
2530150 |
160 | 125 | SDR11 | 14.6 | 150 | 315 | 11.4 |
CAD/Step
|
| TRDE11-RC-180-063 |
2530151 |
180 | 63 | SDR11 | 16.4 | 139 | 352 | 5.8 |
|
| TRDE11-RC-180-075 |
|
180 | 75 | SDR11 | 16.4 | 144 | 348 | 6.8 |
CAD/Step
|
| TRDE11-RC-180-125 |
2530153 |
180 | 125 | SDR11 | 16.4 | 166 | 358 | 11.4 |
CAD/Step
|
| TRDE11-RC-225-125 |
2530156 |
225 | 125 | SDR11 | 20.5 | 178 | 435 | 11.4 |
CAD/Step
|
