Visa alla mått +
| Artikelnummer | RSK | d1 | R | D | i | b | e1 | e2 | Filer |
|---|---|---|---|---|---|---|---|---|---|
| 0560512060 | 4 | NPT1/8 | 5 | 10 | 11 | 3 | 3 | ||
| 0560512065 | 4 | NPT1/4 | 5 | 14 | 11 | 3 | 6.5 | ||
| 0560512100 | 6 | NPT1/8 | 7.5 | 10 | 17 | 5 | 5 | ||
| 0560512110 | 6 | NPT1/4 | 7.5 | 14 | 17 | 5 | 6.5 | ||
| 0560512160 | 8 | NPT1/8 | 9.5 | 10 | 17 | 6 | 6 | ||
| 0560512170 | 8 | NPT1/4 | 9.5 | 14 | 17 | 6 | 6 | ||
| 0560512270 | 10 | NPT1/4 | 11.5 | 14 | 19 | 8 | 8 | ||
| 0560512280 | 10 | NPT3/8 | 11.5 | 14 | 19 | 8 | 8 | ||
| 0560512285 | 10 | NPT1/2 | 11.5 | 19 | 19 | 8 | 14 | ||
| 0560512450 | 13 | NPT3/8 | 15 | 14 | 21 | 11 | 11 | ||
| 0560512454 | 13 | NPT1/2 | 15 | 19 | 21 | 11 | 14 | ||
| 0560512566 | 16 | NPT1/2 | 18 | 19 | 26 | 13 | 13 | ||
| 0560512676 | 19 | NPT1/2 | 21.5 | 19 | 26 | 16 | 16 | ||
| 0560512678 | 19 | NPT3/4 | 21.5 | 20 | 26 | 16 | 16 | ||
| 0560512805 | 25 | NPT3/4 | 27.5 | 20 | 29 | 19 | 19 | ||
| 0560512810 | 25 | NPT1 | 27.5 | 25 | 29 | 22 | 22 |
