NIFE-AS

Svetsände utv. svets/utv. gänga mässing

  • PE100 Övergång
  • Utvändig svets till utvändig gänga i mässing
  • Vatten PN 16 SDR11
  • Gas PN 10
Nollställ
Visa alla mått +
Artikelnummer RSK Dimensionda(OD)sLL1SWGFiler
NIFE-AS-RC-020-R015 2555954 20×1/2203814032½ CAD/Step
NIFE-AS-RC-025-R020 2555955 25×3/4253854336¾ CAD/Step
NIFE-AS-RC-032-R015 32x1/2323884641½ CAD/Step
NIFE-AS-RC-032-R020 32x3/4323904641¾ CAD/Step
NIFE-AS-RC-032-R025 2555956 32×13239246411 CAD/Step
NIFE-AS-RC-032-R032 32x1¼3239546411¼ CAD/Step
NIFE-AS-RC-032-R040 32x1½3239746411½ CAD/Step
NIFE-AS-RC-040-R025 2555958 40x1403.79951501 CAD/Step
NIFE-AS-RC-040-R032 2555957 40x1¼403.710051501¼ CAD/Step
NIFE-AS-RC-040-R040 40x1½403.710351501½ CAD/Step
NIFE-AS-RC-040-R050 40x2403.710751502 CAD/Step
NIFE-AS-RC-050-R025 50x1504.610557601 CAD/Step
NIFE-AS-RC-050-R032 50x1¼504.610757601¼ CAD/Step
NIFE-AS-RC-050-R040 2555959 50x1½504.610957601½ CAD/Step
NIFE-AS-RC-050-R050 50x2504.611457602 CAD/Step
NIFE-AS-RC-063-R032 63x1¼635.811765701¼ CAD/Step
NIFE-AS-RC-063-R040 63x1½635.812165701½ CAD/Step
NIFE-AS-RC-063-R050 2555960 63×2635.812465702 CAD/Step
NIFE-AS075 75x2½756.8133752½
NIFE-AS090 90x3908.2145853
NIFE-AS110 110x411010165884
Artikelnummer NIFE-AS-RC-020-R015
RSK 2555954
Dimension 20×1/2
da(OD) 20
s 3
L 81
L1 40
SW 32
G ½
Artikelnummer NIFE-AS-RC-025-R020
RSK 2555955
Dimension 25×3/4
da(OD) 25
s 3
L 85
L1 43
SW 36
G ¾
Artikelnummer NIFE-AS-RC-032-R015
RSK
Dimension 32x1/2
da(OD) 32
s 3
L 88
L1 46
SW 41
G ½
Artikelnummer NIFE-AS-RC-032-R020
RSK
Dimension 32x3/4
da(OD) 32
s 3
L 90
L1 46
SW 41
G ¾
Artikelnummer NIFE-AS-RC-032-R025
RSK 2555956
Dimension 32×1
da(OD) 32
s 3
L 92
L1 46
SW 41
G 1
Artikelnummer NIFE-AS-RC-032-R032
RSK
Dimension 32x1¼
da(OD) 32
s 3
L 95
L1 46
SW 41
G 1¼
Artikelnummer NIFE-AS-RC-032-R040
RSK
Dimension 32x1½
da(OD) 32
s 3
L 97
L1 46
SW 41
G 1½
Artikelnummer NIFE-AS-RC-040-R025
RSK 2555958
Dimension 40x1
da(OD) 40
s 3.7
L 99
L1 51
SW 50
G 1
Artikelnummer NIFE-AS-RC-040-R032
RSK 2555957
Dimension 40x1¼
da(OD) 40
s 3.7
L 100
L1 51
SW 50
G 1¼
Artikelnummer NIFE-AS-RC-040-R040
RSK
Dimension 40x1½
da(OD) 40
s 3.7
L 103
L1 51
SW 50
G 1½
Artikelnummer NIFE-AS-RC-040-R050
RSK
Dimension 40x2
da(OD) 40
s 3.7
L 107
L1 51
SW 50
G 2
Artikelnummer NIFE-AS-RC-050-R025
RSK
Dimension 50x1
da(OD) 50
s 4.6
L 105
L1 57
SW 60
G 1
Artikelnummer NIFE-AS-RC-050-R032
RSK
Dimension 50x1¼
da(OD) 50
s 4.6
L 107
L1 57
SW 60
G 1¼
Artikelnummer NIFE-AS-RC-050-R040
RSK 2555959
Dimension 50x1½
da(OD) 50
s 4.6
L 109
L1 57
SW 60
G 1½
Artikelnummer NIFE-AS-RC-050-R050
RSK
Dimension 50x2
da(OD) 50
s 4.6
L 114
L1 57
SW 60
G 2
Artikelnummer NIFE-AS-RC-063-R032
RSK
Dimension 63x1¼
da(OD) 63
s 5.8
L 117
L1 65
SW 70
G 1¼
Artikelnummer NIFE-AS-RC-063-R040
RSK
Dimension 63x1½
da(OD) 63
s 5.8
L 121
L1 65
SW 70
G 1½
Artikelnummer NIFE-AS-RC-063-R050
RSK 2555960
Dimension 63×2
da(OD) 63
s 5.8
L 124
L1 65
SW 70
G 2
Artikelnummer NIFE-AS075
RSK
Dimension 75x2½
da(OD) 75
s 6.8
L 133
L1 75
G 2½
Artikelnummer NIFE-AS090
RSK
Dimension 90x3
da(OD) 90
s 8.2
L 145
L1 85
G 3
Artikelnummer NIFE-AS110
RSK
Dimension 110x4
da(OD) 110
s 10
L 165
L1 88
G 4
